Magnetic Induction Counter,Digital Electronic Punch Counter,Metal Sensor, 5-Digits LCD Digital Display 0-99999, Magnetic Induction Proximity Switch

Specification: Item Type: Magnetic Induction Counter Counter Power Supply Type: Built-in Battery Battery Model: AA (AA Dry cell) R6P, Voltage: 1.5V, Capacity: 1500mA Counting Range: 0-99999 Counting Highest Frequency: 20Hz Counting the Minimum Pulse Width: 1ms Diameter of the Opening of the Magnetic Induction Switch φ: 12mm Magnetic Induction Switch Cable Length: 1.15 Meters Magnet Induction Approach Distance: About 10-15mm Magnet Induction Away Distance: ≥35mm Counter Clear Mode: Panel / External Operating Environment Temperature: -5℃ ~ 40℃ Counter Size: Approx. 64 x 38 x 38mm / 2.5 x 1.5 x 1.5in Counter Opening Size: Approx. 61 x 36mm / 2.4 x 1.4in Package List: 1 X Magnetic Induction Counter 1 X Small Magnet 1 X Metal Magnetic Induction Switch 1 X Bracket

• DIGITAL COUNTER: 5-unit tally counter, metal magnetic control induction switch , accurate and counting, no mechanical wear, work and long life.
• DIGITAL COUNTERS TALLY COUNTER: 5-digit large-screen LCD display, counting range of 0-99999; anti-vibration design, effectively preventing data loss, counting can be reset and paused.
• MAGNETIC INDUCTION SENSOR: metal magnetic induction counting, the opening diameter is 12mm; the induction distance is 10-15mm. The highest counting frequency: 20Hz; the smallest counting pulse width: 1mS.
• PANEL SIZE: counter external size 64*38*38mm; counter opening size 61*36mm, compact and easy to install.
• NOTE: The magnet sheet is used on the object to be detected, which is convenient for the detection of the magnetic sensor and thus the speed measurement. The magnetism disappears after 70°C, pay attention to the rotor temperature.
